Truck-mounted crane TLS 65 15towerfor constructionlifting
Add to favorites
Compare this product
Characteristics
- Configuration
- truck-mounted
- Structure
- tower
- Operating environment
- for construction
- Applications
- lifting, loading, handling
- Lift capacity
Max.: 8,000 kg
(17,637 lb)Min.: 1,350 kg
(2,976.2 lb)- Max load at max radius
1,650 kg
(3,638 lb)- Horizontal reach
Min.: 10 m
(32'09" )Max.: 65 m
(213'03" )- Hoisting speed at max load
11 m/min, 37 m/min, 75 m/min
- Crane engine power
33 kW
(44.9 hp)- Swing speed
0.3 rpm, 0.6 rpm, 0.9 rpm
(1.885 rad.min-1, 3.77 rad.min-1, 5.655 rad.min-1)- Total counterweight
16,500 kg, 18,000 kg, 19,250 kg, 20,750 kg, 22,000 kg
(36,376.273 lb, 39,683.207 lb, 42,438.985 lb, 45,745.919 lb, 48,501.698 lb)
Description
We present the latest version of the TLS 65, now referred to as the TLS 65-15, which includes the latest improvements and technical advances that have been steadily incorporated by the Sáez brand in recent years.
The TLS 65-15 is very similar to its predecessor, but due to small structural changes it has the option to hoist up to 4,000Kg in 2 falls, and up to 8,000 Kg in 4 falls. At its maximum radius of 65m, it will lift 1,650 Kg. This crane also offers an endless number of configurations on site, and can be mounted on a wide range of bases, including travelling bogies, cross-base, or foundation anchors.
There is also the option to jack the crane, and the cage and hydraulics are supplied with an innovative climbing-collar system to achieve great heights.
Catalogs
TLS 65 15
11 Pages
