Truck-mounted crane TLS 65 10T SRtowerfor constructionlifting
Add to favorites
Compare this product
Characteristics
- Configuration
- truck-mounted
- Structure
- tower
- Operating environment
- for construction
- Applications
- lifting, loading, handling
- Lift capacity
Min.: 1,900 kg
(4,188.8 lb)Max.: 10,000 kg
(22,046.2 lb)- Max load at max radius
2,090 kg
(4,608 lb)- Horizontal reach
Min.: 10 m
(32'09" )Max.: 65 m
(213'03" )- Hoisting speed at max load
11 m/min, 37 m/min, 75 m/min
- Crane engine power
35 kW
(47.6 hp)- Swing speed
0.3 rpm, 0.6 rpm, 0.9 rpm
(1.885 rad.min-1, 3.77 rad.min-1, 5.655 rad.min-1)- Total counterweight
13,750 kg, 18,000 kg, 19,250 kg, 20,750 kg, 22,000 kg
(30,313.561 lb, 39,683.207 lb, 42,438.985 lb, 45,745.919 lb, 48,501.698 lb)
Description
This version of the TLS 65 is conceived and designed to work exclusively in 2 falls, freeing the user from having to change the reeving configuration to achieve greater weight ranges. The performance of the TLS 65 10T SR is impressive, hoisting a not inconsiderable 10,000 Kg with the trolley out at 15m from the tower. At the maximum radius of 65m, the user can count on a 2,090 Kg tip load.
Due to these characteristics, this crane is widely used on high buildings that require a large load capacity, and thanks to its climbing and anchor-collar system (both internal and external) it smooths the path of any lifting task.
