Truck-mounted crane TLS 75 14Ttowerfor constructionlifting
Add to favorites
Compare this product
Characteristics
- Configuration
- truck-mounted
- Structure
- tower
- Operating environment
- for construction
- Applications
- lifting, loading, handling
- Lift capacity
Min.: 1,700 kg
(3,747.9 lb)Max.: 14,000 kg
(30,864.7 lb)- Max load at max radius
2,090 kg
(4,608 lb)- Horizontal reach
Min.: 10 m
(32'09" )Max.: 75 m
(246'00" )- Hoisting speed at max load
11 m/min, 37 m/min, 100 m/min
- Crane engine power
37 kW
(50.3 hp)- Swing speed
0.3 rpm, 0.6 rpm, 0.9 rpm
(1.885 rad.min-1, 3.77 rad.min-1, 5.655 rad.min-1)- Total counterweight
16,750 kg, 18,250 kg, 19,500 kg, 20,750 kg, 22,000 kg
(36,927.429 lb, 40,234.363 lb, 42,990.141 lb, 45,745.919 lb, 48,501.698 lb)
Description
Like the TLS 75 10T and TLS 75 16T models, much of the tower and jib sections are interchangeable with its sister cranes, so the TLS 75 14T can be adapted to the needs of each job with just a few changes in configuration, and so offers an adaptable load-chart that characterises this TLS 75 range.
With its 75m working radius and hoist potential, this model begins to move into some big numbers, and a clear advantage is that with the 14-ton capacity, it permits the hoist of other machinery besides the materials for construction. At the jib-tip, it is capable of lifting, transporting and placing objects up to 1,700 kg or 2,090 kg, depending on the configuration.
