Truck-mounted crane TLS 75B 18Ttowerfor constructionlifting
Add to favorites
Compare this product
Characteristics
- Configuration
- truck-mounted
- Structure
- tower
- Operating environment
- for construction
- Applications
- lifting, loading, handling
- Lift capacity
Min.: 2,600 kg
(5,732 lb)Max.: 18,000 kg
(39,683.2 lb)- Max load at max radius
3,190 kg
(7,033 lb)- Horizontal reach
Min.: 10 m
(32'09" )Max.: 75 m
(246'00" )- Hoisting speed at max load
15 m/min, 50 m/min, 100 m/min
- Crane engine power
37 kW, 55 kW
(50.3 hp, 74.8 hp)- Swing speed
0.3 rpm, 0.6 rpm, 0.9 rpm
(1.885 rad.min-1, 3.77 rad.min-1, 5.655 rad.min-1)- Total counterweight
15,500 kg, 19,000 kg, 21,000 kg, 22,500 kg, 24,500 kg
(34,171.651 lb, 41,887.83 lb, 46,297.075 lb, 49,604.009 lb, 54,013.254 lb)
Description
The latest edition to the TLS 75 series is yet another significant step forward, demonstrating Saez’s constant evolution and our understanding of how the international construction markets fluctuate. With this model, we see Saez creating and engineering a machine capable of hoisting up to 18,000 Kg effortlessly, and is a testament to the versatility of design to be found in the Saez range.
This heavy-duty crane is capable of handling some 9,000kg out to almost half of its considerable 75m jib, and can load between 2,600kg and 3,190kg at the tip, depending on the configuration.
Evidently, the crane sports all the technical advances in keeping with the range, and can be jacked using the climbing methods, anchoring and bases that the Sáez Group has been developing and offering over the last decade.
