Truck-mounted crane TLS 80 32Ttowerfor constructionlifting
Add to favorites
Compare this product
Characteristics
- Configuration
- truck-mounted
- Structure
- tower
- Operating environment
- for construction
- Applications
- lifting, loading, handling
- Lift capacity
Min.: 2,500 kg
(5,511.6 lb)Max.: 32,000 kg
(70,547.9 lb)- Max load at max radius
3,520 kg
(7,760 lb)- Horizontal reach
Min.: 15 m
(49'02" )Max.: 80 m
(262'05" )- Hoisting speed at max load
15 m/min, 45 m/min, 90 m/min
- Crane engine power
110 kW
(149.6 hp)- Swing speed
0.3 rpm, 0.6 rpm, 0.8 rpm
(1.885 rad.min-1, 3.77 rad.min-1, 5.027 rad.min-1)- Total counterweight
15,500 kg, 17,500 kg, 19,000 kg, 20,000 kg, 21,000 kg
(34,171.651 lb, 38,580.896 lb, 41,887.83 lb, 44,092.452 lb, 46,297.075 lb)
Description
This is the big sister of the TLS 80 model, with its not inconsiderable load capacity of 32,000 kg. This crane seeks to position itself in a market requiring the maximum possible performance, technology and plenty of power.
It’s an adaptable crane, using a large number of parts that are compatible with the other TLS models, and thus offers the greatest possible economic savings without sacrificing performance. This crane with its immense 80m jib is capable of hoisting 32,000 Kg, while maintaining the tip-load capacity of 3,520 Kg in common with the 24T model.
Catalogs
TLS 80 32T
12 Pages
