Truck-mounted crane SL 320luffing jibfor constructionlifting
Add to favorites
Compare this product
Characteristics
- Configuration
- truck-mounted
- Structure
- luffing jib
- Operating environment
- for construction
- Applications
- lifting, loading, handling
- Lift capacity
Max.: 18,000 kg
(39,683.2 lb)Min.: 3,000 kg
(6,613.9 lb)- Max load at max radius
3,200 kg
(7,055 lb)- Horizontal reach
Max.: 60 m
(196'10" )Min.: 10 m
(32'09" )- Crane engine power
45 kW, 67 kW
(61.2 hp, 91.1 hp)- Swing speed
0.7 rpm
(4.398 rad.min-1)- Total counterweight
21,950 kg, 28,700 kg, 30,950 kg, 33,200 kg
(48,391.467 lb, 63,272.669 lb, 68,233.07 lb, 73,193.471 lb)
Description
The SL 320 is a classic! Another true workhorse from Saez Cranes. It was created as an update from the previous model, the SL 240 16T, and offers more tip-load and a further 2T of hoist capacity, taking it to 18 tons.
With a superbly reliable electronic system, tried and tested over 20 years, a 67 kW hoist and jib mechanism, the SL 320 joins the Saez range of very versatile “luffing” crane models. It is an excellent choice for crane rental companies.
Catalogs
SL 320
16 Pages
