Diesel generator set GRUPEL BDGR 1719 kVA
three-phasecontainerized50 Hz

diesel generator set
diesel generator set
diesel generator set
diesel generator set
diesel generator set
Add to favorites
Compare this product


Characteristics

Motor type
diesel
Phase
three-phase
Portability
containerized
Frequency
50 Hz
Applications
industrial, emergency, for construction site, for military applications, for hospitals, for cogeneration
Options and accessories
soundproofed, open type
Power in kVA

Min.: 1,563 kVA
(2,125.09 hp)

Max.: 1,719 kVA
(2,337.19 hp)

Rated capacity

Min.: 1,250 kW
(1,699.5 hp)

Max.: 1,375 kW
(1,869.5 hp)

Voltage

400 V

Length

12,192 mm
(480 in)

Width

2,500 mm
(98 in)

Fuel tank capacity

1,000 l
(264.2 gal)

Height

2,896 mm
(114 in)

Description

The HEAVY range of diesel generators, with power from 800 to 3150kVA, has been specially developed by our R&D+I team to meet industrial needs with high energy demands. This range consists of containerized diesel generators designed to provide low and/or medium voltage power on a continuous basis, as well as to act as a power source in case of emergency. Given their high power and specificity of their canopy, these generator sets are characterized by their adaptability to the needs of each client and versatility in their construction. For this, we have a specialized technical team capable of responding to different requirements and application objectives. With the possibility of including several extra components, this range serves the most demanding and complex applications, demonstrating great reliability. In addition, it is designed to be fully adapted to the specific needs of the installation it serves.

Catalogs

No catalogs are available for this product.

See all of Grupel‘s catalogs

Other Grupel products

HEAVY RANGE
