The container house is composed of top frame components, bottom frame components, columns and several interchangeable wall panels. Using modular design concepts and production technology, modularize a house into standard parts and assemble the houses on the construction site quickly. Top Frame of the Container House Main beam:3.0mm SGC340 galvanized cold-rolled steel profile Sub-beam: 7pcs Q345B galvanizing steel, spec. C100x40x12x1.5mm Bottom Frame of the Container House Main beam: 3.5mm SGC340 galvanized cold-rolled steel profile Sub-beam: 9pcs "π" typed Q345B, spec.:120*2.0 Corner post of the Container House Material: 3.0mm SGC440 galvanized cold rolled steel profile The Main structure of GS Housing container house is more higher than the house in market, normally the beam is lower than 2.5mm. Safety performance cannot be guaranteed. Wall panel system of GS housing container house Outer board:0.5mm thick galvanized color steel plate, the zinc content is ≥40g/㎡, which guarantees anti-fading and anti-rust for 20 years. Insulation layer: 50-120mm thick hydrophobic basalt wool (different thickness can be choosed according to different environment), density ≥100kg/m³, class A non-combustible. Inner board: 0.5mm Alu-zinc colorful steel plate, PE coating The wall panel of GS housing container house has passed 1 hour fireproof test with ASTM standard, which can highly imporve the insulation performance and life safety for users. Painting of GS housing container house Spray graphene powder evenly on the surface of the polished structural part. After heating at 200 degrees for 1 hour, the powder is fully melted and attached to the surface of the structure.
