Hammer crusher PT-1600HS

mobilecrawler

Simple mechanical structure. Accessories complete Generator included Amazing efficiency High crushing ratio(usually 10-25,the highest can upto 50) High precision One-time forming of aggregate high productivity TECHNICAL PARAMETERS PROJECT - NAME - PT-1600HS - COMMENT Feeder - Max feeding size(mm) - 800 - Feeding height (mm) - 3750 - Capacity (m³) - 6 - Vibrating feeder - Length × width（mm) - 3930 × 1450 - Power（KW） - 3.7kw × 2 - Feed capacity(t/h) - 500 - - Length × width (mm) - 4300 × B500 - Power (kw) - 4 - Hammer crusher - Hammer crusher - 1600H - Max feed size(mm) - 800 - Rotor size （mm） - Ø1400 × 1600 - weight(t) - 20 - Crusher power (kw) - 250-4 - Main Conveyor - Height (mm) - 3250 - Length × width (mm) - 12500 × B1200 - Conveyor power - 15 - Return screen - Length × width (mm) - 4500 × 1500 - Power (kw) - 5.5kw × 2 - Transit Conveyor - Length × width (mm) - 2150 × B650 - Power (kw) - 3 - Return conveyor - Length × width (mm) - 8780 × B650 - Power（kw） - 5.5 - Fines conveyor - Length × width (mm) - 6500 × B1000 - Power（kw） - 7.5 - Height(mm) - 2780 - Generator power (kw) - 500 - Total working power(kw) - 306 - Transport dimensions (m) - 18 × 3.7 × 3.8 - Working size(m) - 18 × 5.6 × 3.8 - Description： 1. The parameter in brackets is the onboard generator scheme. 2. Crusher processing capacity is related to stone hardness, feed size, and discharge size. 3. Basic configuration：manual control 、wireless remote control、Automatic feeding system. 4. Options：side conveyor belt 、iron remover 、water spraying system.
