- Guangzhou YuBen Hydraulic Technology Co., Ltd.
Hydraulic hose YB791steelconstructiontransfer
Add to favorites
Compare this product
Characteristics
- Use
- hydraulic
- Material
- steel
- Applications
- construction, transfer, for petrochemical applications, agricultural, lubrication
- Other characteristics
- wire-braided
- Inner diameter
Min.: 4.8 mm
(0.189 in)Max.: 25.4 mm
(1 in)- Outer diameter
Min.: 9.8 mm
(0.386 in)Max.: 26.5 mm
(1.043 in)- Pressure
Min.: 10 MPa
Max.: 32.5 MPa
- Temperature
Min.: -40 °C
(-40 °F)Max.: 100 °C
(212 °F)
Description
Hose Construction
Twin hose is customizable
Inner Tube: nylon
Reinforcement: one or two steel wire braid
Outer Layer: black or other color polyurethane
Suitable to transfer petroleum and water based hydraulic oil, which could be used as lubrication lines and blowout preventer lines, etc. widely apply to hydraulic lifts, agricultural machines and construction machines.
