Venturi vacuum pump GMVP 120/030 lubricatedsingle-stagestainless steel
Add to favorites
Compare this product
Characteristics
- Technology
- Venturi
- Lubrication
- lubricated
- Number of stages
- single-stage
- Other characteristics
- stainless steel
- Ultimate vacuum
Max.: 400 mbar
(5.8 psi)Min.: 33 mbar
(0.48 psi)- Flow rate
Max.: 25 m³/h
(882.87 ft³/h)Min.: 15 m³/h
(529.72 ft³/h)- Power
0.75 kW
(1.02 hp)- Operating temperature
70 °C, 100 °C
(158 °F, 212 °F)- Length
365 mm
(14 in)- Width
160 mm
(6.3 in)- Height
200 mm
(7.87 in)- Noise level
69 dB
- Weight
18 kg
(39.68 lb)
Description
Monoblock design, no coupling.
Plates are stainless steel.
shaft not contact with the medium.
Safe and efficient operation.
Able to pump every kind of gases and vapors.
Works quiet and reduced vibration.
No need to lubrication.
Low operation and investment cost.
Minimum maintenance with high efficiently.
No metallic contact of the rotating parts.
Provide 0 leakproofing with mechanical seal.
