Venturi vacuum pump GMVP 200/055lubricatedsingle-stagestainless steel
Add to favorites
Compare this product
Characteristics
- Technology
- Venturi
- Lubrication
- lubricated
- Number of stages
- single-stage
- Other characteristics
- stainless steel
- Ultimate vacuum
Min.: 33 mbar
(0.48 psi)Max.: 400 mbar
(5.8 psi)- Flow rate
Min.: 65 m³/h
(2,295.45 ft³/h)Max.: 72 m³/h
(2,542.66 ft³/h)- Power
2.2 kW
(2.99 hp)- Operating temperature
70 °C, 100 °C
(158 °F, 212 °F)- Length
520 mm
(20 in)- Width
285 mm
(11.22 in)- Height
340 mm
(13.39 in)- Noise level
70 dB
- Weight
55 kg
(121.25 lb)
Description
Monoblock design, no coupling.
Plates are stainless steel.
shaft not contact with the medium.
Safe and efficient operation.
Able to pump every kind of gases and vapors.
Works quiet and reduced vibration.
No need to lubrication.
Low operation and investment cost.
Minimum maintenance with high efficiently.
No metallic contact of the rotating parts.
Provide 0 leakproofing with mechanical seal.
