Stepper motor controller BAC100 10A/60V

DCprogrammablesingle-axis

BAC100 10A/60V Stepper motor controller with sequence program memory Technical details: Control: Digital I/O, clock/direction signal (RS422 or 24 V) controllable axes: one Control voltage: +24 V to +36 V DC Motor voltage: +24 V to +60 V DC Max. Phase current: adjustable up to 10 A Temperature range: -10° C to +50°C without forced ventilation Current reduction: adjustable Inputs: 6 x +24 V DC Outputs: 2 x +24 V DC Step resolution: 1/8, 1/4, 1/2, 1/1 This controller for your stepper motor is designed for larger motors up to 10 A phase current. It is also easy to operate and quick to commission. In addition, the stepper motor controller has a robust aluminum housing that protects the electronics from external influences and dissipates heat ideally. Optionally, the cooling of the stepper motor controller can be improved with an additional heat sink - this ensures long availability for your series application.
