Tube filling machine TU110
fully-automaticfor creamcanister

tube filling machine
tube filling machine
tube filling machine
tube filling machine
tube filling machine
tube filling machine
tube filling machine
Add to favorites
Compare this product


Characteristics

Operational mode
fully-automatic
Container type
for cream, canister, for tubes
Product applications
food, for viscous products, for paste, for pasty products, oil, for viscous liquids, for edible oil, for high-viscosity products, for cosmetic products, cosmetic cream, for butter, for semi-liquids, for viscous products, for paint
Domain
for the food industry, for the pharmaceutical industry, for the chemical industry, for the cosmetics industry
Type
volumetric, aseptic, in-line, flexible, servo-driven
Number of heads
multi-head
Other characteristics
PLC-controlled, with conveyor, servo-driven
Throughput

Max.: 240 p/min

Min.: 20 p/min

Volume

Max.: 300 ml
(10.1 US fl oz)

Min.: 5 ml
(0.2 US fl oz)

Description

The TU110 is a high quality oval tube filling and closing machine mainly driven by servo motors. Due to its oval design and therefore generous space of the machine it isn’t necessary to remove or change stations by switching from M-tubes to PE-tubes. There is also given a variable order of the individual processing stations of the machine. The tube transport system regulary contains 44 replaceable tube holders. The individual work stations are positioned around the tube conveyor chain. The stations are equipped with separate drives. The machine frame is made of stainless steel and the product contacting parts are made out of AISI 316L. Furthermore there are many options available as well as if special requests are present we will help to find the right solution. TU 110 Ovale Tubenfüllmaschine For high performance we recommend to add our new full automatic tube feeding system. As a result you will save time of your operating staff and in turn of that you will finally save money. There is also the option to integrate a labeler into the tube feeding system. This machine stands out with almost tool-free format change and very short changeover times. To gain an optimal service the machine includes a remote maintenance module.

VIDEO
