Ultrasonic flow meter Q-Eye PSC

radarvolumefor water

The Portable area velocity flow meter is designed for mobile flow monitoring of slightly to heavily polluted media in full or partially full pipes or open channels. It uses advanced Pulsed-Doppler technology to directly evaluate velocity profiles, making it the best choice for sites with non-uniform or rapidly changing flow conditions. Additionally, the Q-Eye PSC Portable measures bi-directional flow over the entire measurement range and near zero flow velocities down to 0.04 m/s. This profiling capacity eliminates the need for on-site calibration, thereby significantly reducing the cost of installation. Sensor: 1 x velocity 1 x water level Pulse: 1 MHz Number of cells: up to 18 cells Range: velocity ± 5.3 m/s water level 0.04-1.3 m expandable via external 4-20 mA sensor Accuracy: ‒ Velocity ± 0.03 m/s from -1.5 m/s to +1.5 m/s ±1 % of reading from -5.2 to -1.5 m/s and +1.5 to +5.2 m/s ‒ Level ± 0.5 % FS (1.5 m) ‒ Flow typically ± 2 %, depending on site conditions Display: 4 lines, 20 characters Keyboard: 4 keys Data logger: 16 GB MicroSD card Communication: Wireless LAN, 4G (LTE) / 3G (HSPA+) / 2G Inputs: max. 2 x 4-20 mA Power supply: 2 x rechargeable batteries, hot swappable, 24 V DC +/- 10% (option) Protection class housing: IP67 Enclosure: HPX® Resin
