Impact testing machine HD-J223

Wheel Impact Testing Machine Minimum1 SET Delivery15 days after order. ModelHD-1052DB CountryChina BrandNameHD PackageEach set protected with resin fiber and PP film, then put into Strong wooden case with operation manual and video inside. PaymentL/C, D/P, T/T PriceFOB, CIF APPLICATION This tester is designed in accordance with EN14619. This machine is used to simulate the condition of the scooter when the front wheel encounters obstacles during riding, and evaluates the ability of the front wheel to withstand the impact of ground obstacles. STANDARD FEATURES Item Description Impact weight 135N, 20kg (handle resistance test) Impact energy 135J Impact height 1m Final impact speed (4.5±0.5)m/s Weight lifting speed 1m/min Maximum impact height 1.2m Height measurement error ±1mm Weight accuracy ±1% Control mode PLC and touch screen control Display LCD touch screen
