Diesel forklift XF seriesgasride-on4-wheel
Add to favorites
Compare this product
Characteristics
- Motor type
- diesel, gas
- Operator
- ride-on
- Other characteristics
- 4-wheel
- Carrying capacity
Max.: 2,500 kg
(5,511.6 lb)Min.: 2,000 kg
(4,409.2 lb)- Lifting height
Max.: 6,500 mm
(255.91 in)Min.: 3,000 mm
(118.11 in)- Overall width
1,155 mm
(45.5 in)- Load center distance
500 mm
(19.7 in)- Weight without load
3,405 kg, 3,705 kg
(7,506.7 lb, 8,168.1 lb)- Ground clearance under mast with load
115 mm
(4.5 in)- Ground clearance at center of wheelbase with load
150 mm
(5.9 in)- Turning circle radius
2,180 mm, 2,245 mm
(85.8 in, 88.4 in)- Travel speed
18.5 km/h, 19 km/h, 20 km/h
(11.5 mph, 11.8 mph, 12.4 mph)- Lifting speed
0.6 m/s
(1.969 ft/s)- Lowering speed
0.5 m/s
(1.64 ft/s)- Rated drawbar pull
19,500 N, 21,000 N
- Gradeability
23 %, 25 %, 27 %, 30 %
- Rated output
37.4 kW, 43.4 kW, 44.8 kW
(50.8 hp, 59 hp, 60.9 hp)- Rated speed
2,400 rpm, 2,700 rpm
(15,079.6 rad.min-1, 16,964.6 rad.min-1)- Cubic capacity
2,230 cm³, 2,488 cm³, 2,615 cm³
(75.4 US fl oz, 84.1 US fl oz, 88.4 US fl oz)- Maximum operating pressure
175 bar
(2,538.2 psi)
