Circuit board K219-A

GROW K219-A Fingerprint Control Board Classification Fingerprint Control Board Power Supply DC12V Stand-by Mode Current 6mA Fingerprint Capacity 120 Output Relay（Max. current: 10A） Technical Parameters ·P1: Power supply：DC12V ·P2: Output：Relay（Max. current: 10A） ·P3: MX 1.0-6P Fingerprint Module (can connect R502,R502-A,R502-AW,R503) ·P4: MX 1.25-6P Fingerprint Module (can connect R300,R301T,R302,R303,R303T,R305,R306,R307,R501) ·Standby current：6mA ·Fingerprint capacity：120 pieces(20 fingerprints per relay position) ·K1-K6 SET Button corresponds to No.1-6 Relay Control board management:Fingerprint, Remote control(IR) (Before operation, it is necessary to wake up standby. Touch the fingerprint module, and the indicator light is on, then it can be set.) Funtion: 1. Have 6 SET Buttons 2. Have 6 Relays 3. One SET Button Controls One Relay 4. Each Relay Can Store 20 Pieces Fingerprint, Total 120 Pieces 5. Same Fingerprint Can be Opened with Different Relay at the Same Time 6. Use SET Button to Register Fingerprints in Different Relay 7. Use SET Button to Delete Single Relay Postion's Fingerprint 8. Use SET Button to Delete All Relay Position's Fingerprint 9. Have Administrative Password 10. Use Remote Control to Register Fingerprints to Different Relay 11. Use Remote Control to Delete Single Relay Postion's Fingerprint 12. Use Remote Control to Delete All Relay Postion's Fingerprint 13. Use Remote Control to Adjust the Time of Different Relays (0.5s-99s)
