Water pump BN series
electricsemi-submersibleimpeller

water pump
water pump
water pump
water pump
water pump
Add to favorites
Compare this product


Characteristics

Fluid
water
Operation
electric
Priming
semi-submersible
Technology
impeller
Domain
industrial, for the nuclear industry
Applications
discharge, cooling, service
Other characteristics
axial, adjustable, large, vertical
Flow

Max.: 178,000 us gal/min
(673,803.29755 l/min)

Min.: 0 us gal/min
(0 l/min)

Head

Max.: 152'00"
(46.33 m)

Min.: 0'00"
(0 m)

Description

Axial Mixed Flow Pumps Vertical, wet pit design pump for Circulating Water Service (including condenser). Specifically designed for the nuclear industry, it features a number of hydraulic designs, and is engineered to fit customer requirements. Design Features of Hayward Tyler Axial Mixed Flow Pumps: Hayward Tyler offers various, wet pit designed pumps that are ideal for applications where large flow capacities at relatively low heads are required. This includes Circulating Water Service (including condenser). Cast or fabricated discharge head located above or below floor Back-pull out design for ease of maintenance Balanced hydraulics reduces thrust loading Replaceable shaft sleeves with hardened material Bearing span optimized to avoid excitation Vertical rigid adjustable coupling allows axial adjustment Multiple material choices to match application Applications Hayward Tyler Axial Mixed Flow Pumps are ideal for the following applications: Cooling Water Condenser Circulating Water Circulating Water
