Curtain hook sewing machine S-CT250

fixedPLCautomatic

S-CT250 Auto Curtain Pinch Pleating Machine with (Auto Feed) Description The improved version of automatic curtain pinch pleat machine with “Automatic Feed Function”. The pleating will be done automatically, and after the materials have been pleated, it will be pushed and fed towards the sewing frame for stitching process automatically. Therefore the pleating result will be more consistent and uniform evenly. It can easily be adjusted by removing or adding pleating metal to do either single, double or triple pleat. The pleating device is independently controlled by a separate Siemens PLC unit that has been programmed to be synchronized with the sewing control system. The rest of the electrical components are Schneider contactor units and Mitsubishi Electric Inverter unit. Technical Parameter - Model No - S-CT250 Sewing Head - S-326G Needle Brand - German Groz Beckert Needle System - DPx17 (Titanium Coated) Hook Brand - Japanese Hirose Hook Hook Type - Shuttle Hook Stitch Length - 0.2 – 12.7mm Sewing Motor - AC Direct Drive Servo Motor Power - 750 W Max. Sewing Speed - 2500 rpm Voltage - 220 V – 50/60 Hz Control Unit - Siemens PLC Inverter - Mitusbishi Electric Contactor and valve - Schneider Electric Packaging Dimension - 1260 x 1120 x 1350 mm Packaging Material - Export Plywood Gross Weight - 230 kg
