Temperature monitoring system HDGC-3920

currentvoltagebattery

Battery on-line monitoring system tester is a on-line battery monitoring and auto maintain system for USP,EPS, DC power supply, communication power supply . The tester has the function of monitoring and alerting for a series of parameters such as battery pack voltage, battery pack current, cell battery voltage, cell battery internal resistance, battery environment temperature, Cell Battery negative temperature and battery voltage balance, residual capacity and discharge. It can automatically maintain balance voltage, which used for on-line monitoring 2V and 12V battery . Features 1) 7 inch color 800*480 touching screen 2) Abundant and beautiful display interface, it can display cell battery voltage , internal resistance and temperature by bar charts and sliding tables . 3) Reliable measurement quality and excellent service life , built in advanced original imported clip. 4) Reliable communication quality and strong interference ability. Isolation RS485 technology can be used for data communication between each single mode or between single mode and monitoring unit , which can effectively avoid communication faults or burning machine caused by electromagnetic interference, common mode interference and differential mode interference. 5) Each single mode adopt internal power supply, the power supply between single mode also is isolated. It reduce the possible of single model full burning caused by wrong connection or main unit fault. 6) Single TA mode can real-time monitor the battery voltage and battery internal resistance and battery temperature . 7) TC mode can monitor the voltage and current of whole group. Voltage range is compatible with 12-600V.
