• It adopts inclined bed design. When doing printing (or die-cutting), the machine will get in touch with the bed in a progressive mode which makes the pressure keep in balance, no matter what it is printed –either background color or fine letters , the machine can print very clearly.
• It is easy to change plate, reducing the loss of test-run material consumption as well as production cost.
• Easy operation which solves the shortage of skilled workers.
• It adopts Taiwan convertor, convenient to adjust the printing speed
• It can finish the printing, laminating, die-cutting ,waste discharging and sheeting at one process
• One cast iron structure, stable and durable.
• The machine is computerized, second print can be achieved.
• All steel rollers are chromed and grinded which makes it more anti-rust and high precision in ink transfer.
• The machine axle uses alloy copper bush with auto lubrication system. This greatly enhances the precision and durability of the machine.
• The option items for this machine are: side punching, cross punching, stamping or UV ink printing.
Plate Dimension: 180×320mm
Max.Print Area 1-2color
3color
4color: 170×140mm
170×95mm
170×70mm(Option)
Max.Paper Width: 180mm
Max.Paper Length: 150mm
Max.Die-cutting Area: 170×170mm
Machine Size: 2100×1100×1650mm
Machine Weight: 1800About
Main Drive Motor: 2.2kw
Vacuum Motor: 0.37kw
