Wire winding machine JWD-RX05

wire winding machine is suitable for winding Dia. 0.05-0.25mm steel wire, copper wire, enameled wire, and more, which can be used for coil processing of products in various industries, such as high-power toroidal transformers, dimmer transformers, stabilizers, sound amplifiers and transformer coils. • This coil wire winding machine is a low nosie. Single chip Microprocessor design, has further higher performance and higher functions; it also has less sensitive to external power fluctuation or to external electromagnetic interference. • Memory use FLASH ROM, capacity capable storing up to 1000 steps winding data, 9 winding parameters, and 5 options can be independently assigned for each step. Off-power memory retention without battery. • JWD-RX05 Winding speed can be specified using the front panel keypad, resulting in easy programming of multi-step, multi-speed settings. • Guiding traverse shaft stepper motor with a constant-current driver offering fast wire guiding speeds. • Guiding traverse shaft offering 10 steps moving speed selection. • Number of windings : 50~3000T • Wire Dia. : 0.05~0.25mm • Winding speed : 0~2800 • Memory : 1000 group data • Ring width : 2.0~6.0mm • Magnetic ring dimension range : L13~20mm W7~16mm H4~7.5mm • Power supply : 220V 50Hz • Machine weight : 40kg • Machine dimension : 900mmx700mmx600mm LxWxH
