Four-quadrant servo-drive HCF

DCRS-232CANopen

With the HCF Servo drive you can supply your drives directly from a 24V or 48V network and is therefore optimally designed for use in the demanding world of automation. It has inherited its functionality from its "big brother", the HCE. Thus the HCF also has positioning functionality at the highest level, a robust mechanical concept, CANopen CiA 402 support and safe stop in accordance with EN 954-1 category 3, and much more. The HCF servo drive is specially designed for direct supply from a 24 / 48 V mains. This enables an extremely compact and cost-optimised design which is limited to the essential elements of the drive unit. Switch frequency [kHz] 8, 16 (Factory setting 8 kHz) Power rating [kVA] 0.55 Cable cross-section [mm²] 1.5...2.5 Logic supply [VDC] 24 The HCF servo drive is a cost-optimized, DC powered 24 V or 48 V motor controller for use in the demanding world of precision automation technology. The HCF features high precision positioning functionality, a sturdy mechanical design, CANopen CiA 402 support, safe stop according to Category 3 of IEC 954-1, and much more.
