For can-making company to slit tinplate precisely. It is a necessary corollary equipment of high speed resistance welding machine.
Equipped with Siemens electric control components and NSK bearings. The knives are made of entire carbide.
1)Max slitting dimension: 1200mm × 1200mm
2)Min slitting dimension: 600mm × 600mm
3)Slitting thickness: 0.12-0.50mm
4)Slitting speed: 30SPM
5)Slitting diagonal tolerance: ≤0.05mm
6)Max 1st slitting quantity: 6 strips
7)Max 2nd slitting quantity: 18 blanks
8)Power consumption: 12 Kw
