CAD software CloudWorx for Intergraph Smart® Isometrics

modelingconfigurationcreation

CloudWorx for Intergraph Smart® Isometrics helps you quickly create piping isometric documents from a point cloud with no need for a 3D model. The CloudWorx add-on uses the Leica Geosystems HDS Cyclone™ software platform to provide access to point cloud data inside Intergraph Smart® Isometrics. This powerful combination enables you to perform a plant walkdown without leaving the comfort and safety of your office. Ease-of-use The easily understood sketching functionality and automated drawing creation means that users do not need CAD or 3D modeling skills and enables experienced piping designers to be very productive in creating as-built piping data. Integration CloudWorx for Smart Isometrics is unique in supporting the direct integration of point cloud data with a piping isometric document and in enabling the user to define the piping configuration separately from its dimensions. Practical Document The emphasis is on producing a practical, usable document for regulatory compliance, planning, inspection and fabrication as quickly and as cost-effectively as possible.
