Mass spectrometer ion source IG20

A 5keV Argon or Oxygen ion source for UHV surface analysis applications The IG20 features a high brightness electron impact gas ion source which is designed specifically for oxygen capability but is also suitable for use with inert and other gases. Thin Films Optical Coating Electronic Materials Nuclear Materials The IG20 is designed as primary ion beam for SIMS, Auger and XPS applications for imaging and depth profiling, however, the internally generated raster scan and wide range of operating parameters make it suitable for sample cleaning and surface science experiments. Twin user switchable filaments ensure continued operation in the case of a blown filament – which may be replaced at the user’s convenience. Intense ion beam with 100 µm spot size and energies from 0.5 – 5 keV High current density, up to 4.5 mA/cm2 Electron impact ion source with Argon and Oxygen capability Steering optics for line scattering and beam rastering in depth profiling 3° offset in the ion gun column for optimum rejection of neutrals Beam blanking facility for rapid beam switching in rastering applications Source differential pumping for reduced chamber gas load Easily replaceable twin filament assembly Sweep rates down to 64 µs Integrated operation with SIM and EQS probes for direct raster rate / area control
