Temperature control using heating conductor with HTI controller
Applications: Heating low viscosity and gaseous media, such as water, oils, lyes, paints, acids or air.
The heating element inside the hose has direct contact with the media. This ensures optimum heat transfer
This configuration means the heating hose has a small outer diameter and is very flexible.
No thermal insulation is required up to an operating temperature of 60°C.
Rated voltage - 230 V AC
Rated power - approx. 60 W/m
Pressure hose type - PTFE DN 10 to 12 mm, T1 – T2
Connection fitting - AG or ½'' union nut
Connector head - stainless steel or galvanised steel / 100 bar pressure
Heating - PTFE heating conductor, insulated
Outer protection - stainless steel braiding from the main hose
Temperature sensor - ntegral control system (HTI)
Connecting cable - 1.5 m
Plug connection - Plug for HTI controller
Fuse protection - on-site circuit breaker (optional ex works)
Production lengths - 10, 20, 40, 70 m
Protection type - up to IP54 (EN 60529), protection class I
Tolerance - ±5°C
