Diesel generator set HZA1-5C T5

three-phase50 Hzdirect fuel injection

This HATZ diesel engine runs on a 4 strikes-cycle with a direct injection type. Model 1D 81C has a natural aspiration, one vertical cylinder and a rated output of 4,9 kW prp or 5,4 kW on standby. It works on an air cooling system with a displacement of 0,667 L. The bore and stroke sizes are 100 x 85 mm. The engine uses lube oil CCMC-D4-D5-PD2/API CD-CE-CF-CG/SHPD. The generator has 4 poles and an S-5 6,5 frame mounting. It has H class insulation and an IP23 enclosure compliant with IEC-34-5 standards. The single bearing generator has a compound voltage regulator and a flexible coupling disc. It has a standard (vacuum impregnated) coating. The self-regulated exciter system incorporates brushes.
