Engine Specifications 1.500
Rated Output: 37,7 prp ; 41,5 standby
Manufacturer: FPT_IVECO
Model: F32 SM 1A
Engine Type: Diesel 4 strokes-cycle
Injection Type: Direct
Aspiration Type: Turbocharged
Ciylinders Arrangement: 4 - L
Bore and Stroke: 99 x 104
Displacement: 3,2
Cooling System: Liquid (water + 50% glycol)
Lube Oil Specifications: ACEA E3 - E5
Compression Ratio: 17:1
Fuel Consumption StandBy: 11,7
Fuel Consumption 100% PRP: 10,6
Fuel Consumption 80 % PRP: 8,5
Fuel Consumption 50 % PRP: 5,6
Lube Oil Consumption Full Load: 0,5 % of fuel consumption
Total oil capacity including tubes, filters 10,5
Total Coolant Capacity: 19,27
Governor Type Mechanical
Air Filter Type Dry
Inner diameter exhaust pipe: 45
Diesel engine
4 strokes-cycle
Water-cooled
12V Electrical system
Radiator with blowing fan
water separator decanting filter (no visible level)
Mechanical governor
Dry air cleaner
Hot components guards
Mobile components guards
Generator
Poles: 4
Winding Conections (standard): Star-serie
Frame Mounting: S-3 11"1/2
Insulation: H class
Enclosure (according IEC-34-5): IP23
Exciter System: self-excited, brushless
Voltage Regulator: A.V.R. (Electronic)
Bearing: Single bearing
Coupling: Flexible disc
Coating type: Standar (Vacuum impregnation)
