Engine Specifications 1.500
Rated Output: 242 prp
Manufacturer: SCANIA
Model: DC9 71A (02-02)
Engine Type: Diesel 4 strokes-cycle
Injection Type: Direct
Aspiration Type: Turbocharged and aftercooled
Ciylinders Arrangement: 5-L
Bore and Stroke: 130 x 140
Displacement: 9,3
Cooling System: coolant
Lube Oil Specifications: ACEA E3,E4,E5 or E7
Compression Ratio: 16:1
Fuel Consumption 100% PRP: 59,98
Fuel Consumption 75 % PRP: 46,5
Fuel Consumption 50 % PRP: 31,43
Lube Oil Consumption Full Load: 0,2
Total Oil Capacity: 38
Governor Type Electrical
Air Filter Type Dry
Inner diameter exhaust pipe: 90
Diesel engine
4 strokes-cycle
Water-cooled
24V Electrical system
Radiator with blowing fan
Water separator decanting filter (visible level)
Electronic governor
Sender WT
Senders OP
Low water level sensor
Dry air cleaner
Hot components guards
Mobile components guards
Generator
Poles: 4
Winding Conections (standard): Star-serie
Frame Mounting: S-1 14"
Insulation: H class
Enclosure (according IEC-34-5): IP23
Exciter System: self-excited, brushless
Voltage Regulator: A.V.R. (Electronic)
Bearing: Single bearing
Coupling: Flexible disc
Coating type: Standar (Vacuum impregnation)
