Digital clamp multimeter CM437 series

portable600 V1000 V

AC/DC CLAMP METER CM4375 Easily Get Into Tight Spaces Innovative Jaw Provides Remarkable Accessibility Overview Hioki clamp on meters are best-in-class measuring devices incorporating Hioki’s expertise in current sensing technology. The CM4375 is a 1000A AC/DC True RMS clamp meter that features a uniquely designed slim jaw that lets you easily get into the narrow gaps between cables in crowded electrical distribution boxes without fear of damaging the cables or the clamp meter. The broad -25℃ to 65℃ operating temperature range and IP54 dustproof and waterproof enclosure to enable professionals to work quickly in challenging situations including the development, repair, and maintenance of equipment and devices such as electric vehicles. Additionally, the high-voltage DC measurement capability of up to 1700 V (*1) is ideal for the clamp maintenance inspections of electrical and solar power equipment. CAT IV 600 V | CAT III 1000 V Key Features • - Easily get into tight spaces between cables thanks to thin sensor structure • - Measure up to 1000 A • - Automatic AC/DC function helps boost work efficiency • - Measure DC voltages of up to 1700 V (*1) • - Simultaneously measure inrush current in RMS and crest values • - Expanded -25 °C to 65 °C operating temperature range • - 3 year guarantee DC Current range - 1000 A, (Max. display 999.9 A) , Basic accuracy: ±1.3% rdg. ±0.3 A (at 30.1 A - 999.9 A) AC Current range - 1000 A (Max. display 999.9 A, 10 Hz to 1 kHz, True RMS), Basic accuracy 45-66 Hz: ±1.3% rdg. ±0.3 A (at 30.1 A - 900.0 A) Crest factor - 1.5 DC+AC Current range - 1000 A (DC, 10 Hz to 1 kHz, True RMS), Basic accuracy DC, 45-66 Hz: ±1.3% rdg. ±1.3 A (at 30.1 A - 900.0 A)
