Piston valve F series manualfor airnormally closed
Add to favorites
Compare this product
Characteristics
- Type
- piston
- Operation
- manual
- Media
- for air
- Other characteristics
- normally closed, automatic, low-pressure, normally open
- Pressure
Max.: 6,000 psi
Min.: 0 psi
- Temperature
Max.: 1,200 °F
(649 °C)Min.: -423 °F
(-253 °C)
Description
Mini-Hippo Air Operators are available for both normally open service (spring to open/air to close) and for normally closed service (air to open/spring to close). These piston air operators provide remote automatic on/off operation of valves and can be controlled by means of an air regulator, an electrical solenoid, or a manual low pressure valve in the user's air supply line. Air inlet is 1/8" NPT. Air pressure requirement ranges from 50 to 90 psi.
The Mini-Hippo air operators may be supplied with the valves and operating pressures shown in table.
To order simply specify catalog number of valve and type operation required.
EXAMPLES:
30-11HF4-MHNC (normally closed)
10-12AF6-MHNO (normally open)
10-15AF4-MHNO-MHNC (normally open/normally closed)
