Power transducer U10b

Two free adjustable analog outputs 4-20 mA, relay output (limit value or quantity pulse), M-Bus output. Click here for more M-Bus information. Power supply 24 V DC. Configurable via an optional keypad in the housing lid or via WiFi interface. DISPLAYED INDICATORS standard flow rate [m³/h] or [l/min] mass flow [kg/h] standard volume [m³] mass [kg] standard flow velocity [m/s] IP PROTECTION TYPE IP65 TYPE OF PROTECTION ATEX categorie 3G and 3D (zone 2 and 22) (option) SENSOR INPUT for sensors TA10 and TA Di with thin-film sensor element SENSOR OUTPUT 2 analog output 4-20 mA, linear, freely configurable relay for quantity pulse WiFi (optional) M-Bus (optional)
