- Hydraulics - Pneumatics
- Valve
- Ball valve
- Honeywell Environmental & Combustion Controls EMEA
Ball valve V5832A serieselectrictemperature controlfor water
Add to favorites
Compare this product
Characteristics
- Type
- ball
- Operation
- electric
- Function
- temperature control
- Media
- for water
- Body
- threaded, compact, brass
- Applications
- heaters, for pipe, coil
- Number of channels
- 2-way
- Associated function
- balancing
- Other characteristics
- modulating, bypass, thermoelectric
- DN
15 mm, 20 mm
(0.591 in, 0.787 in)- Pressure
16 bar
(232.1 psi)- Temperature
Min.: 2 °C
(36 °F)Max.: 120 °C
(248 °F)
Description
V5832A series 2-way valves are available in DN15 and DN20 sizes, for use in compact zone valve applications.
V5832A series is available in DN15 and DN20 size, with external pipe thread and flat seal for maximum pipe connection flexibility. An impressive range of KVS values are available, to suit a wide range of applications. 2.5mm stroke valves are available for 2-P on/off control, as well as 6.5mm stroke versions for modulating control.
Valves are used with compact thermo-electric and electric actuators for a compact assembly. Flow characteristic for 6.5mm stroke valves is equal percentage. Valve action: A-port is open with the stem in its top position.
