Ball valve V5825B series
manualshut-offflow control

Ball valve - V5825B series  - Honeywell Environmental & Combustion Controls EMEA - manual / shut-off / flow control
Ball valve - V5825B series  - Honeywell Environmental & Combustion Controls EMEA - manual / shut-off / flow control
Ball valve - V5825B series  - Honeywell Environmental & Combustion Controls EMEA - manual / shut-off / flow control - image - 2
Add to favorites
Compare this product

Characteristics

Type
ball
Operation
manual
Function
shut-off, flow control
Media
for water
Body$
threaded, welded, small
Applications
heating, for pipes, air conditioning
Material$
stainless, bronze
Number of channels
2-way
Associated function
balancing
Other characteristics
DIN, compact, high-pressure, with seal, modulating
DN

15 mm, 20 mm, 25 mm, 32 mm
(0.591 in, 0.787 in, 0.984 in, 1.26 in)

Pressure

25 Pa
(0 psi)

Temperature

Min.: 2 °C
(36 °F)

Max.: 130 °C
(266 °F)

Description

V5825 series 2-way high pressure valves are available in DN15, DN20, DN25, and DN32 sizes, for use in compact zone valve applications, especially suited to high pressure applications such as district heating stations. V5825 series is available in DN15, DN20, DN25, and DN32 sizes, with external pipe thread and flat seal for maximumg pipe connection flexibility. An impressive range of KVS values are available, to suit a wide range of applications. All models are pressure balanced to achieve maximum shut-off performance in district heating applications requiring safety function. Together with ML6435 and ML7435 actuators the valves carry DIN / EN 14597 certification. 6.5mm stroke for superior modulating control. Valves are used with 300N and 400N electric actuators for a compact assembly. Flow characteristic is modified equal percentage. Valve action: A-port is closed with the stem in its top position.
