Gas drain HP 560

automaticmanualmechanical

The three-way purge block HP 560 was designed in order to guard against the lack of space in modern gas cylinder cabinets. For this purpose a short cylinder conections and the close fitting purge valves are installed, which also simplifies the cylinder change and increase the operating safety of the entire ar- mature. The purge block is characterized by a compact design and the purge valves installed lateral over the cylinders shoulders. It has a small dead volume and by the aban- donment of purge capillary a quick evacuation is possible. Specific features: A modular construction of the three-way purge block. Assembly and disassembly of all moun- tings attached from the front. Designed especially for gases with high re- quirements for purity up to 6.0, safety and density. The stations are ECD – suitable through our special-cleansing-procedure.
