Stainless steel bin activator EVK series

Discharge out of silos with mass flow avoids clearance volumes and segregation, permits high loads. • Reliable discharging of difficult bulk solids • Uniform material movement across the entire width of the silo • No segregation • Perfect mass flow without dead zones • No bridging • Gentle handling of the material to be discharged, without particle degradation • Improved dosing precision Horizontal vibrations, generated by an unbalanced motor, are transferred to the particle mass. The particles are accelerated; they collide and repel each other. This frees particles that have clogged together, and the bulk-solid is then capable of flowing. • Stable, vibration-resistant design, e.g. longitudinal and transverse ribs, especially in the drive section • Stable weld joints, fully penetrated and counter-weld • Suspension is both fall-safe and resilient to vibrations, by means of break-proof, forged hangers • A special profile collar, form-fit and dust-proof, connects the vibrating bottom with the rigid weld-on ring of the silo • Load-relief at the outlet
