Exhaust gas hose J 5-3
EPDMhigh-temperature

Exhaust gas hose - J 5-3 - HUANYU HOSE CO., LTD. - EPDM / high-temperature
Exhaust gas hose - J 5-3 - HUANYU HOSE CO., LTD. - EPDM / high-temperature
Exhaust gas hose - J 5-3 - HUANYU HOSE CO., LTD. - EPDM / high-temperature - image - 2
Add to favorites
Compare this product


Characteristics

Use
for exhaust gas
Material
EPDM
Applications
high-temperature
Inner diameter

Max.: 152 mm
(5.984 in)

Min.: 50 mm
(1.969 in)

Outer diameter

Max.: 165 mm
(6.496 in)

Min.: 57 mm
(2.244 in)

Pressure

Max.: 0.4 bar
(5.802 psi)

Min.: 0.025 bar
(0.363 psi)

Temperature

Max.: 190 °C
(374 °F)

Min.: -40 °C
(-40 °F)

Description

The J 5-3 EPDM MEMORY HOSE series of high-temperature suction tubes from JUMBOFLEX provide crush and vibration proof services. These very flexible tubes are ideally used for engine exhaust gas suctioning. They provide chemical resistant operations, and offer flame retarding services. They are engineered from EPDM and Nylon Helix. When properly used with exhaust gas funnels and an enough supply of air, these tubes are capable of operating in temperatures ranging from -40 to +190 °C. It also has a 0.8 millimeters of thickness.

Catalogs

Other HUANYU HOSE CO., LTD. products

VEHICLE EXHAUST EXTRACTION HOSE
