Hydraulic press KHF700

fine-blankingframeautomatic

General Description: Hydraulic Fineblanking Press is not a standard stamping press. Fineblanking presses are unique by providing three specific motions: a stinger motion, which brings the stinger plate up and holds the material in place during blanking; a blanking motion, which provides the blanking force to push the part into the die cavity; and a counter pressure motion, which holds the piece against the blank punch during blanking and ejects the piece part from the die cavity after blanking is complete. KHF 700 Hydraulic Fineblanking Press is characterized by wider worktable, higher accuracy, efficiency and reliability. Features: 1. Overall welded frame structure guarantees the lightness and stability of the fine blanking machine. 2. Hydraulic Fineblanking Press is driven by simple-structured cylinder to ensure the enough power driving and protect the sliding block from bending and deforming. 3. Concisely designed with single pump, single motor and power accumulator of high capacity, our power system features low power consumption, high efficiency, and less malfunction. 4. The blanking speed, the pressure as well as the back pressure can all be adjusted on the control panel due to the adoption of accurate rotation control technology. 5. The advanced and creatively-designed mold installment technology can realize convenient exchange of the molds. 6. Equipped with protection device, the pressure and position of Hydraulic Fineblanking Press can be flexibly adjusted to keep the molds from accidental damage.
