Screw flow divider FD50-45hydraulic
Add to favorites
Compare this product
Characteristics
- Technology
- screw
- Flow type
- hydraulic
- Operating pressure
11 bar, 345 bar
(160 psi, 5,004 psi)- Flow rate
Max.: 3,420 l/h
(15 us gal/h)Min.: 19 l/h
(5 us gal/h)
Description
The FD50-45 is a screw-in cartridge, spool type flow divider/combiner valve. It provides pressure compensated proportional division of inlet flow or combining of two return flows regardless of system operating pressure conditions. The valve provides synchronizing flow in dividing and combining modes. The valve is intended for use in mineral based or synthetic hydraulic fluids with lubricating properties.
Features
Hardened parts for long life.
Quiet, modulated response.
Wide operating flow range.
Synchronizing in dividing and combining modes.
Floating cage — high installation torque.
Industry-common cavity.
Unit Weight:
0.49 kg (1.07 lb)
Cavity:
VC10-4
