Cartridge flow divider FD56-45

4-wayhydraulic

The FD56-45 is a screw-in cartridge, spool type flow divider/combiner valve. Operation The cartridge valve provides pressure compensated proportional division of inlet flow or combining of two return flows regardless of system operating pressure conditions. The valve provides synchronizing flow in dividing and combining modes. Features Hardened parts for long life. Quiet, modulated response. Wide operating flow range. Synchronizing in dividing and combining modes. Floating cage — high installation torque. Industry common cavity. Fluids: Mineral based or synthetic hydraulic fluid with lubricating properties Fluid Viscosity Range: 7.4 to 420 cSt Maximum Operating Contamination Level: 18/16/13 per ISO 4406 Unit Weight: 0.38 kg (0.83 lb) Internal Wetted Surface Area: 403 cm² (62.4 in²) Cavity: VC16-4 HVC16-4 for applications Cartridge Installation Torque: 133 to 138 N-m (98 to 102 ft-lb) 258 to 285 N-m (190 to 210 ft-lb) Orientation Restriction: None
