Electrically-powered hydraulic power unit HPR micro
Add to favorites
Compare this product
Characteristics
- Power source
- electrically-powered
- Other characteristics
- micro
- Operating pressure
Max.: 200 bar
(2,901 psi)Min.: 0 bar
(0 psi)- Nominal power
Max.: 800 W
(1.1 hp)Min.: 150 W
(0.2 hp)- Flow rate
Max.: 3.5 l/min
(0.92 us gal/min)Min.: 0 l/min
(0 us gal/min)- Tank capacity
Max.: 1 l
(0.26 gal)Min.: 0 l
(0 gal)
Description
Designed by Hydraproducts these HPR micro hydraulic power packs are manufactured using the latest CNC machining centre technology.
By simply reversing the motor a double acting hydraulic cylinder can be controlled. Each power pack contains a dual pilot check valve to hold the load as well as an adjustable relief valve on each A and B pressure lines.
Double acting hydraulic cylinders are not the only application, hydraulic motors can also be sucessfully controlled. Applications such as tensioners, slew ring drives and positioning systems.
