Fiber laser cutting machine iGR-P 3015
for metalsheet metalNC

Fiber laser cutting machine - iGR-P 3015 - igoldencnc - for metal / sheet metal / NC
Fiber laser cutting machine - iGR-P 3015 - igoldencnc - for metal / sheet metal / NC
Fiber laser cutting machine - iGR-P 3015 - igoldencnc - for metal / sheet metal / NC - image - 2
Fiber laser cutting machine - iGR-P 3015 - igoldencnc - for metal / sheet metal / NC - image - 3
Fiber laser cutting machine - iGR-P 3015 - igoldencnc - for metal / sheet metal / NC - image - 4
Fiber laser cutting machine - iGR-P 3015 - igoldencnc - for metal / sheet metal / NC - image - 5
Fiber laser cutting machine - iGR-P 3015 - igoldencnc - for metal / sheet metal / NC - image - 6
Add to favorites
Compare this product


Characteristics

Technology
fiber laser
Material
for metal
Product handled
sheet metal
Control type
NC
Workpiece loading
manual loading
Phase
three-phase
Other characteristics
automatic, high-speed, CE, with exchange table
X travel

1,500 mm
(59.06 in)

Y travel

3,000 mm
(118.11 in)

Z travel

300 mm
(12 in)

Cutting speed

180 m/min

Laser power

Max.: 12,000 W

Min.: 500 W

Overall length

8,230 mm
(324 in)

Overall width

3,140 mm
(124 in)

Height

2,300 mm
(91 in)

Weight

4,000 kg
(8,818.49 lb)

Description

The full-protective laser cutting machine is equipped with an exchange table and a laser protective observation window. The protective design meets the European CE safety production standards to ensure the safe operation of the equipment and the personal safety of the operators. Full Protective Cutting Machine Description: Equipped with 1000w-12000w fiber laser, the standard working area is 1500*3000mm, which can be upgraded to 1500*4500mm, and the power of 2000w and above is equipped with an independent cabinet with built-in air conditioner. Full-Protection Fiber Laser Cutting Machine Features: AUTOMATIC LUBRICATION SYSTEM The automatic lubrication system provides a fixed amount of lubricating oil for the protective laser cutting machine to ensure the high-speed operation of the equipment, with abnormal alarm and liquid level alarm functions. The system greatly improves the cutting accuracy and effectively extends the service life of the transmission mechanism. INTELLIGENT ALARM SYSTEM Intelligent travel protection, automatic monitoring of the operating range of components, installation of international machine tool standard limit springs, the laser cutting head is built-in capacitor height adjustment function, collision stop, improve equipment and life safety protection, reduce the incidence of accidents, improve cutting efficiency. SECURITY SYSTEM Automatic alarm function for abnormal working status of the automatic sheet metal cutting machine, and push it to the operation interface through the control center, improve the efficiency of equipment abnormal troubleshooting, reduce potential safety hazards, and reduce maintenance costs.
