H2S sensor LOGAZ-H2S series

electrochemical

WIRELESS H2S SENSOR LOGAZ-H2S • - H2S gas measuring range 0-2000ppm • - Wireless setting with Rfid technology • - Communication : local only by radio and 2G/4G (NB-IoT, LTE-M) • - Memory : up to 500 000 measures • - Logger enclosure rating IP68 • - Gas cells interchangeable on-site • - Replaceable lithium battery This new sensor integrates a logger, communication, energy, the H2S gas sensor while maintaining a long autonomy. The measurement is performed by an electrochemical cell, the measuring head is easily interchangeable on-site and embarks its calibration. Data logger - Integrated 500 000 measures Access point - Oui Antenna HF - Internal or external depending on model Optional GSM Antenna - External on sensors with built-in modem Radio range - 100m open field , WIJI® protocol® Operating temperature - -40 …85°C Housing - ABS 20%FV Logger enclosure rating - IP68 Energy - 3,6V/17 Ah ou 3,6V/ 34Ah (logger with built-in modem) Programming - AVELOUR software, by radio Connection (W/O the need to activate the sensor) Weight including battery and antenna - 550g optional Atex Kit - ATEX II 3G Ex ic nA IIB T4 Gc, Tamb : -20°C…+60°C Certifications - CE – FCC: SE6A001 – IC : 10983A-A001 Typical measuring range - 0-2000ppm Max. overexposure - 10 000ppm Cell accuracy - ± 0,15% FS Resolution - 1 ppm Operating temperature range - -30°C to +50°C Relative humidity range - 15 to 90% non-condensing Pressure range - 80 to 120kPa Cell enclosure rating - IP66 Dimensions - Ø54 x 58mm Weight - 108g Calibration - Integrated to the cartridge
