Test fixture Terminal Clamp Jig for Crimp Pull Test CH-5000N

CH-5000N is terminal clamp jig for crimp pull test with 5000N capacity. It is ideal for high-capacity wire crimp pull test, using with test stand and force gauge. It enables testings complying with the corresponding part of JIS standard. Features - Ideal for high-capacity wire crimp pull test - Suitable for ring terminals with inner diameter of 4mm to 12mm - Reduces slippage and breakage of the covering due to shear stress - Complies with the corresponding part of JIS standard Related Standard - JIS C2805 (2010) [Crimp-type terminal lugs for copper conductors](corresponding part only) Specifications - Capacity: 5000N - Sample Diameter: 4mm to 12mm (inner of ring terminal) See the specifications for further information.
