Spring locating pin CP720

Spring locating pin - CP720 - Imao Corporation
Spring locating pin - CP720 - Imao Corporation
Spring locating pin - CP720 - Imao Corporation - image - 2
Add to favorites
Compare this product

Go to the Imao Corporation website for more information

Characteristics

Options
spring

Description

Pin for the quick change over of fixture plates. The tapered pin plus movable tapered bushing allow easy operation with excellent repeatability by firm dual contact. Precise locating with simple screw tightening design! ●Locating Repeatability : 10μm ●Mounting Diameter : φ16, φ25, φ38, φ56
