Thermal-magnetic residual current circuit breaker B10R4025-300

AC voltageoverloadresidual current

RCD 10KA, 300mA 3 Pole N, 25 Amp, 415VAC Type AC Specifications • Neutral Position : R • Residual Current Type : AC • Temperature Range °C : -25 to 55 °C • Number of Poles : 3P+N • Residual Current (mA) : 300.00 • Cable sizes (AWG) : 2AWG • Cable size (mm²) : 35mm The IMO range of miniature circuit breakers have been designed for protection of electrical installations against overload and short circuits and are manufactured in accordance with IEC 60898-1 Technical Data • Handle central-tripping function for circuit fault indicating • New front design; cover and handle in arc shape • Contact position indicating window; transparent cover to carry label • High short circuit capacity • Suitable for terminal and Pin/Fork type busbar connection • Finger protected connection terminals • Handle padlock device Tripping characteristics in accordance with B, C and D type curves • Curve B: 3-5 In • Curve C: 5-10 In • Curve D: 10-20 In
