Rinsing washing tunnel LAES 20,12

for cartsfor framesfor racks

WASHING CLOSETS Closets for washing shelves, frames, carts, trays, etc. Washing closets with mobile pressure showers for shelves measuring 1200x1200x2000 mm. When the shelves enter the unit a washing cycle automatically begins, entering a re-circulation circuit. Rinsing takes place immediately afterwards via an upper sprinkler fed directly from the mains ALES Model The circuit is made up of a pressure pump, tank, water heating unit and fixed roller batteries duly positioned and steered towards the shelves LAES Model The circuit is made up of a pressure pump, tank, water-heating unit and mobile battery of steered rollers. Washing takes place via a sweeping movement when the battery of rollers advances and retreats in cycles. Guides and supports to position shelves. Pressure pump with stainless steel body aisi 304. Electrical system with safety elements. Built in stainless steel aisi 304. Built according to the European Directive 89/392CEE. Optional Heating unit with elements. Roll up door. Pneumatic door. 2 shelf entry exit door. Detergent supply pump. Shelf lift. Water/water heat exchanger . Extractor for deck beam exit
