Universal hardness tester NEMESIS 9800

RockwellVickersfloor-mounted

This custom-made universal hardness tester with a force range of 1kgf – 3000kgf covers all hardness scales: Brinell, Vickers, Knoop, Rockwell, Superficial Rockwell, HVT & HBT, Ball indentation for plastic ISO 2039/1. The motorized descending test head can be equipped with 6, 7 or 8 position turret and has standard 3 indenters and 3 obectives. The IMPRESSIONS™ full tester and configuration control can be easily operated by means of the 15’’ industrial HD Touch screen. Due to the enormous workpiece accommodation of 1500mm (H) X 1500mm (D), the NEXUS 9800 is perfectly suitable for heavy and very large parts. The second Z-axis has a 150mm/300mm stroke descending test head offering unique flexibility. Highlights Scales: Rockwell, Superficial Rockwell, Brinell, Vickers, Knoop, HVT & HBT, Plastic ISO 2039/1, Carbon Test Forces: 200gf – 3000kgf Camera: 18 Mega pixel, Full HD camera system, with zoom and autofocus Overview Camera: Full HD optical zoom stage overview camera Objectives: 0.7X, 2.5X, 5X, 10X, 20X, 40X, 60X, 100X 8 Position Turret: 3 indenters, 3 objectives, Class 2 laser for positioning and optional integrated overview camera Load App. System: Fully automatic, Load cell, closed loop, force feedback Control: Fully integrated Windows Controller, SSD hard disk, Windows 10 operated, IMPRESSIONS™ advanced workflow software, includes automatic measurement, keyboard & mouse
